The core of the MIKE+ user interface

The Model Manager is the core of the MIKE+ user interface. The wealth of features enable you to efficiently go through all phases of preparing the model input data as well as analyse and present results from the simulation engines. The Model Manager provides:

• Network data management for storm water collection systems, wastewater collection systems, water distribution systems, rivers and 2D flooding
• Feature-rich GIS functionality powered by Esri’s ArcGIS, effective time series data management, comprehensive data processing and manipulation tools as well as powerful data visualisation capabilities for all data entities
• Result interpretation and presentation within MIKE+ Result Viewer, but also for an unlimited number of users with our freeware MIKE VIEW

Surface water hydrodynamics including distributed rainfall/infiltration and 2D Non-Newtonian flow

• The Flexible Mesh (FM) solver offers maximum flexibility for detailed and tailored meshes. Its advanced handling of buildings, roads and rainfall is perfectly suited for urban flooding studies.
• By directly using your geographical land cover data, you can easily represent the spatial variability of the roughness in your domain. The depth varying roughness feature accurately represents the impact of different land covers along the simulation.
• Structures like weirs, dikes, culverts can be directly implemented in the 2D model domain
• Parallelisation enables 2D model performance enhancements through use of multiple cores and GPU-cards

Simulate unsteady flow in pipe or channel networks, as well as in the natural river

SWMM
This module includes US-EPA SWMM5 engine for modelling stormwater and wastewater systems from primarily urban areas. Simulates unsteady flow in pipe and channel networks including:

• Junctions, outfalls, dividers and storage units. Links, pumps, orifices, weirs, outlets, transects and regulators
• Subcritical and supercritical flow conditions in partially full, full and pressurised pipes and open channels
• Catchment rainfall routing and infiltration with option of modelling the effects from I/I, LIDS, snow pack and groundwater

MIKE1D Pipeflow
This module simulates unsteady flow in pipe and channel networks, including:

• Circular manholes, junctions, retention basins, soakaways. Standard and flexible cross-sections, weirs, orifices, pumps, valves, flow regulators and storm water inlets.
• Simulation of partially full, full and pressurised pipes and open channels
• Continuous simulations involving RDI and long-term statistics
• Optimisation of network capacity
• Wet weather management to reduce CSO
• Design and optimisation of real-time controls
• Sustainable stormwater management

Connections can be made seamlessly between collection systems and river networks.

MIKE1D Rivers
This module simulates the flow in the natural river. It supports weirs and culverts and is typically used with the Rainfall Runoff module to represent hydrological inflows from the catchment. Connections can be made seamlessly between pipe network and river. Includes AUTOCAL, a general tool for parameter estimation and sensitivity analysis that automatically utilises available multicore resources.

Rainfall-runoff, advanced control structures and pollutant transport modelling

Rainfall Runoff
This module includes multiple rainfall-runoff models such as time area method, kinematic wave, linear reservoir and UHM. Also, an RDI module for the generation of continuous inflow typically applied for simulating slow response inflows, such as infiltration.

Control
This module features advanced real-time control capabilities. It makes the definition of complex operational logic for regulators.

Transport (AD)
This module includes pollution transport by advection and dispersion including fine sediments as well as sediment transport of coarse sediments.

For real-time flood forecasting

Data Assimilation (DA)
Data assimilation and real-time flood forecasting, including continuous model state updating during simulation, Kalman filter and uncertainty assessments.

Control
This module features advanced real-time control capabilities. It makes the definition of complex operational logic for regulators.

Transport (AD)
This module includes pollution transport by advection and dispersion including fine sediments as well as sediment transport of coarse sediments.

Water quality modelling

MIKE+ ECO Lab
This module allows modelling of all kinds of water quality aspects, the fate of dissolved substances, or biological relations on population or individual level in sanitary systems and combined systems. MIKE+ ECO Lab includes templates for modelling of biological processes (including BOD, DO and E.Coli) and Hydrogen Sulphide (H2S).
